Chainsawr Piston and Cylinder Kits / piston and cylinder

The Chainsawr's aftermarket piston and cylinder kits are the perfect combination of quality and economy.

Every one of our kits is produced to our higher than standard specifications and inspected by us for correct fitment and quality.

We have used and installed every make and model combination we carry on our own saws and repairs here at the shop to absolutely verify that they work and fit well.

The quality of the cut, cast iron rings on our pistons and sold individually is equal to OEM from any premium manufacturer.

-------------------------------------------------------------------------------------------------------

We feel there are 2 problems that affect aftermarket parts in general but especially cylinders.

#1:  Tons of them are made wrong, and sold retail by people who have no idea what they are looking at or how to test it, so the customer ends up with a part that doesn't work.   We have tried and regularly use everything we sell and screen every cylinder we go through personally for problems, so we don't have that issue.  We have literally recycled hundreds of incorrectly made brand new parts here over the years in our screening and testing of new products.
#2 Most aftermarket parts are sold directly to consumers, not to trained dealers who are knowledgeable about servicing the product.  For example, say your top end got scored because the carburetor is set too lean and your fuel filter is plugged.  Many consumers who would just buy an aftermarket top end kit and throw it in to fix the problem don't know enough to troubleshoot and fix the underlying problem.  So, the new parts score again.  Then the untrained consumer blames it on the new parts, and the aftermarket parts gain undeserved bad reputation.  Be sure to correct the problem that caused the top end to score in the first place!
Ready to ship
(1 in stock)

Husqvarna 353 Chainsaw 45mm Piston and Cylinder 537 25 31-04 NEW OEM (upstairs)

 45mm diameter, top end motor kit includes: piston, ring, wrist pin, bearing, and keeper clips, cylinder head. 537253104  New part from closed out dealer  Fits Husqvarna model 353 chainsaw, but will fit on 346 XP, 350, 350, 350 EPA, 351, 351 EPA

View
$184.25
Ready to ship
(2 in stock)

Stihl MS461 Chainsaw Piston and Cylinder Kit 1128 020 1250 NEW

 52mm Bore, top end motor kit includes: cylinder head, piston, rings, wrist pin and keeper clips. 1128 020 1250  New AFTERMARKET part  Fits Stihl MS461 MS461c MS 461

View
$103.25
Ready to ship
(3 in stock)

Stihl MS201t Chainsaw Piston and Cylinder Kit 1145 020 1200 NEW

 Top end motor kit includes: cylinder head, piston, rings, wrist pin and keeper clips. 1145 020 1200  New AFTERMARKET part  Fits Stihl MS201 t MS201t MS 201t 201 t

View
$103.25
Ready to ship
(1 in stock)

Stihl MS461 Chainsaw Piston and Cylinder Kit 1128 020 1250

 52mm Bore, top end motor kit includes: cylinder head, piston, rings, wrist pin, bearing and keeper clips. 1128 020 1250  Good used shape. Has broken fins.  Fits Stihl MS461 MS461c MS 461

View
$97.75
Ready to ship

Partner K650 Active Cut-Off Saw Piston and Cylinder 506 09 92-12 NEW

 Top end motor kit includes: cylinder head, piston, rings, wrist pin, and keeper clips.  New AFTERMARKET part  Fits K650 Active, Active II, K-650 Series, and can be retro fit onto many older 65cc and 70cc chainsaw models as well such as 7000.

sale
View
$93.74 - $124.99
Ready to ship

Stihl 028 Super Chainsaw Piston and Cylinder 1118 020 1203 NEW

 46mm Bore top end motor kit includes: cylinder head, piston, rings, wrist pin, and keeper clips.  New AFTERMARKET part  Fits Stihl 028S, 028 Super.  Is a direct bolt on retrofit for smaller displacement 028 series saws: 028av, 028wb, 028 AV Woodboss

sale
View
$93.74 - $124.99
Sold Out!

Stihl MS362 Chainsaw Piston and Cylinder Kit 1140 020 1205 NEW

 47mm Bore, top end motor kit includes: cylinder head, piston, rings, wrist pin and keeper clips. 1140 020 1205  New AFTERMARKET part  Fits Stihl MS362 MS362c MS362CM MS 362 c cm m

sale
View
$84.25 - $99.00
Sold Out!

Stihl 019t Chainsaw Piston and Cylinder Set 1132 020 1200 NEW (Misc 7777)

 Piston and cylinder set 40mm bore. 1132 020 1200  New AFTERMARKET part  Fits Stihl 019T, 019 T, MS190t, MS 190t, MS 190 t.  Make sure you verify the part number you need before ordering.

sale
View
$74.25 - $99.00
Ready to ship

Husqvarna 346xp Chainsaw 50cc Piston and Cylinder Kit 544 14 29-08 NEW

 44.3mm diameter, 50cc top end motor kit includes: piston, ring, wrist pin, and keeper clips, cylinder head. 544 14 29-08  New AFTERMARKET part  Fits Husqvarna 346XP 346XPG 346 XP XPG after serial number 095200001.  Can also be retrofit onto all of the following models: 350 351 353 346xp (pre-20...

sale
View
$74.25 - $99.00
Ready to ship

Stihl MS390 Chainsaw Cylinder and Piston kit NEW 1127 020 1216

  Complete cylinder and piston kit.  Includes piston, rings, wrist pin and keepers, and cylinder. 49mm bore. 1127 020 1216, 11270201216   New aftermarket part   Fits MS390, MS 390 , 039 The cylinder is drilled and tapped for the compression release valve.

sale
View
$74.25 - $99.00
Ready to ship
(3 in stock)

Stih 051 AV chainsaw cylinder and piston kit 1111 020 1200

  Complete cylinder and piston kit.  52mm bore, tapped for compression release port and includes plug.  Includes cylinder, piston, rings, wrist pin, and keepers.  Stihl part number 1111 020 1200   New aftermarket part   Fits 050 051AV, TS510

sale
View
$74.25 - $99.00
Sold Out!

Stih 038 AV chainsaw cylinder and piston kit 1119 020 1201 (Misc. 1Q)

  Complete cylinder and piston kit.  50mm bore.  Includes cylinder, piston, rings, wrist pin, and keepers.  Stihl part number 1119 020 1201   New aftermarket part   Fits 038av, 038 Super

sale
View
$74.25 - $99.00
Ready to ship
(3 in stock)

Stih 023 AV chainsaw cylinder and piston kit 1123 020 1214 (Misc. 1Q)

  Complete cylinder and piston kit.  40mm bore.  Includes cylinder, piston, rings, wrist pin, and keepers.  Stihl part number 1123 020 1214   New aftermarket part   Fits MS230, and 023

sale
View
$74.25 - $99.00
Ready to ship
(2 in stock)

Stih 021 AV chainsaw cylinder and piston kit 1123 020 1219 (Misc. 1Q)

  Complete cylinder and piston kit.  40mm bore.  Includes cylinder, piston, rings, wrist pin, and keepers.  Stihl part number 1123 020 1219   New aftermarket part   Fits MS210, and 021

sale
View
$74.25 - $99.00
Ready to ship
(3 in stock)

Stihl MS200t Chainsaw Piston and Cylinder Kit 1129 020 1202 NEW

  Complete top end motor kit, 40mm bore.  With piston, wrist pin, piston ring, and keepers and cylinder. 1129 020 1202   New AFTERMARKET part   Fits Stihl 020t, MS200 t, MS 200t

sale
View
$74.25 - $99.00
Sold Out!

Stihl MS180 018 chainsaw cylinder and piston kit (Misc. 1B)

  Complete cylinder and piston kit.  38mm bore.  Includes cylinder, piston, rings, wrist pin, and keepers.  Stihl part number 1130 020 1208   New aftermarket part   Fits 018 and MS180

sale
View
$59.96 - $79.95
Sold Out!

Stihl 024AV Chainsaw 42mm Piston and Cylinder 1121 020 1212 NEW

 42mm Bore top end motor kit includes: cylinder, piston, rings, wrist pin, and pin keeper clips. 1121 020 1200, 1121 020 1202, 1121 020 1212, 1121 020 1210  New AFTERMARKET part  Fits Stihl 024 AV Woodboss Farmboss etc MS240

sale
View
$49.95 - $99.00
Ready to ship

Stihl MS170 017 chainsaw cylinder and piston kit NEW

  Complete cylinder and piston kit.  37mm bore, no compression release port.  Includes cylinder, piston, rings, wrist pin, and keepers.  Stihl part number 1130 020 1207   New aftermarket part   Fits 017 and MS170 MS170c.  Will also fit 018 018c MS180 MS180c    On sale for direct import price, ge...

sale
View
$49.95 - $99.95
Sold Out!

Poulan 2450 Chainsaw Piston and Cylinder Set 530069932 NEW

 Top end motor kit includes: cylinder, piston, ring, wrist pin and keepers. 530-069932,  530 06 99-32   New AFTERMARKET part  Fits Many AV spring mounted Poulan, Craftsman, and Poulan pro chainsaws. 2250 2450 2550 etc.

sale
View
$37.46 - $49.95
Ready to ship
(1 in stock)

Partner K650 Active Cut-Off Saw Piston Ring 503 28 90-17 NEW NOS (bin 26)

 piston ring  New old stock oem from closed out dealer.   Fits K650 Active, Active II K700 active K700 active II

View
$10.00
